PB6330

PB Flat Plate

The Pegasus PB range of traction battery/deep cycle monoblock flat plate series has advanced flat grid plates and paste formulation, giving extended service life. It is especially suited to arduous deep cycle semi traction applications and has a productive run-time.

PB6330 Benefits

  • Advanced separator design and paste formulation gives true 500 cycle performance.
  • Enhanced performance gives extended running times and lower maintenance.
  • Superior performance giving productive run-time.
Enquire About
SKU: c19dc3a8aa33 Categories: , , , , , , , , , Tag:

Description

Model Industry Reference Volts Capacity in Ah Dimensions (mm) Weight
(kg)		 Terminal
Type		 Find out more
C5 C10 C20 C25 C75 C100 Length Width Height
PB6210 GC2/ DT05 6 175 202 175 383 105 234 262 181 276 27 LPT / UT View details
PB6225 GC2 / FM505 6 185 216 185 445 115 250 262 181 276 28.6 LPT / UT View details
PB6240 GC2 / FM525 6 195 230 195 488 132 267 262 181 276 30.7 LPT / UT View details
PB6245 DIN 91801 6 200 235 200 500 135 273 244 191 276 31 LPT View details
PB6260 GC2H / FM545 6 215 250 215 530 145 289 262 181 295 33 LPT/ UT View details
PB6330 J305 6 253 317 253 711 195 368 315 180 368 44 UT View details
PB6420 L16 6 344 404 344 850 220 468 315 180 415 52 UT View details
RS70DT BCI/70DT 12 45 45 208 180 210 12.5 LPT View details
PB12105 27TMX/H 12 82 101 82 175 45 117 324 175 245 26 DT View details
PB12115 12 95 111 95 200 51 128 324 175 245 28 DT View details
PB12150D DIN 96151 12 110 135 110 260 60 156 345 170 285 36 AP View details
PB12150 FM5275 12 120 144 120 280 70 167 327 181 276 37 LPT / UT View details
PB12205 J185P 12 168 197 168 380 104 229 394 178 378 52 UT View details
PB1280 DIN 95602 12 67 77 67 133 34 89 278 175 190 20 AP View details
PB1285 24TMX 12 70 82 70 140 36 95 280 171 245 21 DT View details
PB8170 GC8 / T875 8 145 163 145 296 75 190 264 181 276 29 LPT / UT View details
